IRFP90N20D

Utsource certified original

Utsource certified original parts provide the following guarantees:

1. Utsource guarantees 100% original.

2. Utsource certified original parts can be returned and refunded unconditionally within 90 days.

CAP,TANT,100UF,10V,LOW ESR,D PKG

Mounting: THT
Brand: International Rectifier
DateCode: 14+
Package / Case: TO-247
Polarity: N
RthJC max: 0.26K/W
VDS max: 200V
Package: TO-247
Ptot @ TA=25°C max: 580W
Qgd typ nominal: 87nC
Tj max: 175°C
VGS max: 30V
Type: N
Product Group: TO-247
Additional Information: Electrical
X-Selling-Products-RFS: Yes
Budgetary Price €/1k nominal: 2.31
VGS(th) max: 5V
VGS(th) min: 3V
VGS(th) nominal: 4V
Technology: IR MOSFET?
Qualification: Standard
Language: SPICE
Product Category: Power MOSFET
Program Memory (macro) nominal: 0kByte
Data Memory (macro) nominal: 0kByte
Polarity N OR N+N(macro): Yes
Type (macro): No
Polarity P+N(macro): No
Technology Silicon-PN (macro): No
Technology Silicon-Schottky (macro): No
Technology Silicon-Carbide-Schottky (macro): No
Technology Any (macro): No
Polarity N Depletion(macro): No
Polarity P(macro): No
