TDE1767DP INTERFACE CIRCUIT RELAY AND LAMP-DRIVER

Sales：34

113521

5.0 out of 5 stars

1 star 0.3%

2 star 0%

3 star 0.2%

4 star 0.4%

5 star 99.1%

Total products: 2400393

Total sales: 11261046

Average lead time: 0 Hour

Delivery times (Express): 0

Delivery times (Post office): 0

Favorite

TDE1767DP

NEW

Utsource certified original

Utsource certified original parts provide the following guarantees:

1. Utsource guarantees 100% original.

2. Utsource certified original parts can be returned and refunded unconditionally within 90 days.

Description

INTERFACE CIRCUIT RELAY AND LAMP-DRIVER

Not found, similar datasheet recommended

ECAD Module
Series: -
Brand: STMicroelectronics
DateCode: 94+
Package / Case: DIP8
Packaging: Tube
Part Status: Obsolete
Switch Type: Relay, Solenoid Driver
Number of Outputs: 1
Ratio - Input:Output: 1:1
Output Configuration: High Side
Output Type: Bipolar
Interface: On/Off
Voltage - Load: 6 V ~ 45 V
Voltage - Supply (Vcc/Vdd): Not Required
Current - Output (Max): 1.2A
Rds On (Typ): -
Input Type: Inverting, Non-Inverting
Features: -
Fault Protection: Current Limiting (Adjustable), Over Temperature
Operating Temperature: -25°C ~ 85°C (TA)
Supplier Device Package: 8-DIP
Base Part Number: TDE1767

All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.

ECAD Module

Product Attributes

Description: TDE1767DP is a low-power, low-voltage, 8-pin DIP (dual in-line package) integrated circuit (IC) manufactured by STMicroelectronics. It is a low-power, low-voltage, high-performance, low-cost, 8-bit microcontroller. Features: 8-bit microcontroller Low-power, low-voltage operation High-performance, low-cost On-chip RAM, ROM, and I/O On-chip oscillator On-chip analog-to-digital converter On-chip watchdog timer On-chip serial port On-chip pulse width modulator Applications: TDE1767DP is suitable for a wide range of applications such as consumer electronics, automotive, industrial, and medical applications. It can be used for motor control, lighting control, remote control, data acquisition, and other embedded control applications. (For reference only)

● OPEN GROUND PROTECTION

● HIGH OUTPUT CURRENT

● ADJUSTABLE SHORT-CIRCUIT PROTECTION

● INTERNAL THERMAL PROTECTION WITH EXTERNAL RESET

● LARGE SUPPLY VOLT AGE RANGE

● ALARM OUTPUT

● INPUT VOLTAGE CAN BE HIGHER THAN VCC

● OUTPUT VOLTAGE CAN BE LOWER THAN GROUND (VCC - VO ≤ VCC[max])

DESCRIPTION

The TDE1767, A/TDE1787, A are a monolithic amplifiers designed for high current and high voltage applications, specifically to drive lamps, relays, stepping motors.

The devices are assentially blow-out proof. The output is prois protected from short-circuits with the positive supply or drive. In addition thermal shut down is provited to keep the IC from overheathing. If internal dissipation becomes too high, the driver will shut down to prevent excessive heating. The output stays null after the overheating is off, if the reset input is low. If high the output will alternatively switch-on and off until the overload is removed.

The devices operates over a wide range voltages from standard 15 V operational amplifier supplies to the single +6V or +48V used for industrial electric systems. Input voltages can be higher than in the VCC.

An alarm output suitable for driving a LED is provited. This LED, normally on (if referred to ground), will die out or flash during an overload depending on the state of the reset input.

The output is low in open ground conditions.
