Description
40P color DuPont line male to female head 40 in a row of 10CM
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
| Parameter | Description |
|---|---|
| Type | Dupont Connector |
| Gender | Male to Female |
| Number of Pins | 40 |
| Pin Configuration | 40 pins in a row |
| Pitch | 2.54mm (0.1 inch) |
| Length | 10cm |
| Color | 40 Different Colors |
| Material | High-quality plastic with gold-plated contacts |
| Operating Temperature | -40°C to +85°C |
| Current Rating | 1A per pin |
| Voltage Rating | 250V AC/DC |
| Insulation Resistance | >100MΩ at 500V DC |
| Contact Resistance | <50mΩ |
| Insertion Force | 0.5N to 1.5N per pin |
| Pull-out Force | 3N to 5N per pin |
| Mounting Type | Through-hole |
| Packaging | Bulk or Tape & Reel (depending on quantity) |
Identify the Pins:
Insertion:
Connection Verification:
Soldering:
Handling:
Storage:
Maintenance:
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $0.82740 | US $0.77776 | US $0.77776 |
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
Substitute Product
| Substitute Product Name | Description |
|---|---|
| 10cm 40 Pin Female to Male Jumper Wire | Set of 40 jumper wires with male to female connectors, 10 cm in length. Ideal for prototyping and connecting components in circuits. |
| 10cm Dupont 40-Pin Male to Female Jumper Wires | High-quality Dupont cables, 10 cm long, featuring 40 male to female connections. Perfect for breadboard and Arduino projects. |
| 10cm 40-Pin Dupont Wire Male to Female | 40-pin ribbon wire with male to female ends, measuring 10 cm. Suitable for a wide range of electronics and DIY applications. |
| 10cm Female to Male 40 Pin Jumper Wire | 40 individual wires in a single strip, 10 cm in length, with female to male connectors for versatile electronic circuit setups. |
Product Usage
A 40-pin Dupont line (male to female) cable is a versatile component used in various electronic circuits and projects. Here are some types of circuits and applications that may use such cables:
Prototyping on Breadboards:
Microcontroller Projects:
Sensor Interfacing:
Module Integration:
IC Testing and Interfacing:
Robotics:
DIY Electronics:
LCD/OLED Displays:
Home Automation:
Educational and STEM Kits:
Connecting an Ultrasonic Sensor to an Arduino:
Components Needed:
Connections:
Arduino Code:
Required#define TRIG_PIN 9
#define ECHO_PIN 10
void setup(){
Serial.begin(9600);
pinMode(TRIG_PIN, OUTPUT);
pinMode(ECHO_PIN, INPUT);
}
void loop(){
long duration, distance;
digitalWrite(TRIG_PIN, LOW);
delayMicroseconds(2);
digitalWrite(TRIG_PIN, HIGH);
delayMicroseconds(10);
digitalWrite(TRIG_PIN, LOW);
duration = pulseIn(ECHO_PIN, HIGH);
distance = (duration/2) / 29.1;
Serial.print(distance);
Serial.println(" cm");
delay(500);
}
In this example, the male-female Dupont cables provide the necessary connections between the Arduino and the ultrasonic sensor, enabling the sensor to function correctly within the circuit.
