SKIIP28ANB16V1(1PCS)

Name: SKIIP28ANB16V1
Brand: Semikron
SKU: 12374229
Price: 55.875 USD
Availability: InStock
Rating: 4.6 (864 reviews)

Utsource certified original

Utsource certified original parts provide the following guarantees:

1. Utsource guarantees 100% original.

2. Utsource certified original parts can be returned and refunded unconditionally within 90 days.

Description

3-phase bridge rectifier + brake chopper

Manufacturer Part Number: SKiiP28ANB16V1
Brand: Semikron
DateCode: 18+
Package / Case: Module
Category: Discrete Semiconductor
Warranty: 100% Perfect Functions

Model comparison: SKIIP28ANB16V1 vs GD25PIT120C5S comparison

All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.

The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！

Product Attributes

Parameter	Description	Min	Typ	Max	Unit
V_DC	DC Input Voltage	500	-	800	V
I_C	Continuous Collector Current	-	1600	-	A
I_C,peak	Peak Collector Current (10 μs, 1% duty cycle)	-	3200	-	A
T_j	Junction Temperature	-40	-	175	°C
R_th(j-c)	Thermal Resistance, Junction to Case	-	0.14	-	K/W
R_th(c-s)	Thermal Resistance, Case to Heat Sink	-	0.01	-	K/W
f_sw	Switching Frequency	-	-	20	kHz
V_CE(sat)	Collector-Emitter Saturation Voltage at I_C = 1600 A, V_GE = 15 V	-	2.0	-	V
E_on	Turn-On Energy at I_C = 1600 A, V_DC = 800 V	-	150	-	mJ
E_off	Turn-Off Energy at I_C = 1600 A, V_DC = 800 V	-	120	-	mJ
t_d(on)	Turn-On Delay Time	-	0.15	-	μs
t_r	Rise Time	-	0.3	-	μs
t_d(off)	Turn-Off Delay Time	-	0.15	-	μs
t_f	Fall Time	-	0.3	-	μs

Instructions for Use:

Mounting:
- Ensure proper heat sinking to maintain the junction temperature within the specified range.
- Use thermal paste or thermal interface material between the module and the heat sink to improve thermal conductivity.
Electrical Connections:
- Connect the DC input voltage within the specified range (500 V to 800 V).
- Ensure that the continuous collector current does not exceed 1600 A.
- For peak currents, do not exceed 3200 A for durations of 10 μs with a 1% duty cycle.
Thermal Management:
- Monitor the junction temperature to ensure it does not exceed 175°C.
- Use the provided thermal resistance values to calculate the required heat sink size and cooling method.
Switching Operations:
- Operate within the switching frequency limit of up to 20 kHz.
- Be aware of the turn-on and turn-off energies to optimize the drive circuit and minimize power losses.
Storage and Handling:
- Store the module in a dry, cool place away from direct sunlight and corrosive environments.
- Handle with care to avoid mechanical damage or electrostatic discharge (ESD).
Safety Precautions:
- Follow all safety guidelines and regulations when handling high-voltage and high-current components.
- Ensure proper grounding and isolation to prevent electrical hazards.

(For reference only)

SKIIP28ANB16V1

High-power intelligent power module (IPM) integrating IGBTs, drivers, and protection circuitry for industrial motor drives.

1600 V/28 A rated IGBTs with integrated gate drivers

Integrated overcurrent, overtemperature, and undervoltage lockout protection

Optimized for 3-phase inverter applications up to 15 kW

Low-inductance press-fit packaging for high reliability

V_CE(max)	1600 V
I_C(nom)	28 A
f_sw(max)	20 kHz
T_j(max)	150 °C
