TLE6209R 7 A H-Bridge for DC-Motor Applications

Sales：40

113521

5.0 out of 5 stars

1 star 0.3%

2 star 0%

3 star 0.2%

4 star 0.4%

5 star 99.1%

Total products: 2400741

Total sales: 11611558

Average lead time: 0 Hour

Delivery times (Express): 0

Delivery times (Post office): 0

Favorite

TLE6209R

USED

Utsource certified used parts

Utsource certified used parts provide the following guarantees:

1. Utsource will inspect the goods, including appearance inspection (no serious damage to the appearance), select qualified and honest suppliers, and ensure 98% qualification rate.

2. Some parts are tested by machine.

3. Utsource certified parts can be returned and refunded unconditionally within 60 days.

Description

7 A H-Bridge for DC-Motor Applications

Not found, similar datasheet recommended

ECAD Module
Motor Type: BLDC
Brand: Siemens
Package / Case: SOP-20
Output Configuration: Full Bridge
Maximum IGBT Collector Current: 6A
Maximum Collector Emitter Voltage: 40 V
Mounting Type: Surface Mount
Package Type: DSO-20-37
Maximum Operating Supply Voltage: 40 V
Pin Count: 20
Typical Switching Frequency: 2MHz
Minimum Operating Temperature: -40 °C
Height: 3.5mm
Width: 11mm
Dimensions: 15.9 x 11 x 3.5mm
Length: 15.9mm
Maximum Operating Temperature: +150 °C

All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.

ECAD Module

Product Attributes

Description: The TLE6209R is an advanced, monolithic low-side driver IC. It has sophisticated control logic, including low-side driver, logic and diagnostic functions. Features: - High side / low side driver with single power supply - Low-side output voltage: 0.5V to 40 V - High current capability: up to 5A - Thermal protection with temperature warning - High speed protection - Open load detection - Open load diagnostic - Short circuit protection - Over-current protection Applications: The TLE6209R is designed for automotive applications and is suitable for driving LEDs, relays, solenoids, valves, and other loads. It can also be used for motor control and other automotive applications. (For reference only)

Features

● Delivers up to 6 A continuous and 7 A peak current

● Optimized for DC motor management applications

● Very low RDS ON of typ. 150 mΩ @25℃ per switch

● Operates at supply voltages of up to 40V

● Overvoltage Protection against transients up to 45 V

● Outputs fully short circuit protected

● Standard SPI-Interface, daisy chain capability

● Adjustable chopper current regulation of up to 7 A

● Temperature monitor with prewarning, warning and shutdown

● Over- and Undervoltage-Lockout

● Open load detection

● Detailed load failure diagnosis by SPI

● Minimized power dissipation due to active free-wheeling

● Low EMI due to voltage slope regulation

● Very low current consumption (typ. 20 μA @ 25℃) in stand-by (Inhibit) mode

● Enhanced power PG-DSO-Package

● Green Product (RoHS compliant)

● AEC Qualified

Functional Description

The TLE 6209 R is an integrated power H-Bridge with D-MOS output stages for driving bidirectional loads such as DC-Motors. The design is based on Infineons Smart Power Technology SPT which allows bipolar, CMOS and power D-MOS devices on the same monolithic circuit.

Operation modes forward (cw), reverse (ccw) and brake are invoked by two control pins PWM and DIR. Protection and a reliable diagnosis of overcurrent, openload, short-circuit to ground, to the supply voltage or across the load are integrated. Detailed diagnostic information is given via the 8 bit SPI status word. An integrated chopper current limitation limits the current e.g. to reduce power dissipation during mechanical block of a DC motor. Several device parameters can be set by the SPI control word. A three-level temperature monitoring with prewarning, warning and shutdown is included for controlled operation under critical power loss conditions. The full protection and diagnosis capability make the device suitable especially for safety relevant applications, e.g. in automotive ECUs.

Preview of the first 3 pages of the data sheet
