Description
Microprocessor Supervisory & Reset Circuits, On Semiconductor
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
| Parameter | Symbol | Conditions | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|
| Input Voltage | V_IN | Operating Range | 2.7 | - | 5.5 | V |
| Output Voltage | V_OUT | Fixed | - | 3.3 | - | V |
| Quiescent Current | I_Q | V_IN = 5V, No Load | - | 10 | - | μA |
| Dropout Voltage | V_DROPOUT | I_OUT = 100mA, V_IN = 3.3V | - | 170 | - | mV |
| Load Regulation | ΔV_LOAD | I_OUT: 0mA to 100mA | - | 2 | - | % |
| Line Regulation | ΔV_LINE | V_IN: 2.7V to 5.5V | - | 0.1 | - | % |
| Power Supply Rejection Ratio | PSRR | @ 120Hz | - | 60 | - | dB |
| Operating Junction Temperature | T_JOP | Continuous Operation | -40 | - | 85 | °C |
| Storage Temperature | T_STG | Storage | -40 | - | 125 | °C |
Power Supply Connection: Connect the input voltage (V_IN) within the range of 2.7V to 5.5V. Ensure that the power supply is stable and free from excessive noise.
Output Configuration: The device provides a fixed output voltage of 3.3V. No external components are required for setting the output voltage.
Quiescent Current Management: The quiescent current is very low at 10μA under no-load conditions. This helps in minimizing power consumption in battery-operated devices.
Thermal Considerations: Operate the device within the junction temperature range of -40°C to +85°C. For storage, ensure temperatures do not exceed -40°C to +125°C.
Load Regulation: The load regulation is maintained at 2%, ensuring minimal change in output voltage as the load current varies from 0mA to 100mA.
Line Regulation: The line regulation is excellent at 0.1%, maintaining output stability over the entire input voltage range.
Power Supply Rejection Ratio (PSRR): The device offers a high PSRR of 60dB at 120Hz, effectively rejecting fluctuations in the input voltage.
Capacitor Requirements: Use appropriate input and output capacitors to stabilize the voltage and reduce ripple. Typical values are 1μF ceramic capacitors for both input and output.
PCB Layout Recommendations: Place the input and output capacitors as close as possible to the device's pins. Ensure a solid ground plane to enhance thermal performance and reduce electromagnetic interference (EMI).
Handling Precautions: Handle the device with care to avoid damage from electrostatic discharge (ESD). Follow standard ESD handling procedures.
