MAX 1232 Microprocessor Monitor
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
| Parameter | Symbol | Conditions | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|
| Supply Voltage | VDD | Operating | 4.5 | 5.0 | 5.5 | V |
| Supply Current (Quiescent) | IQ | All channels off | - | 30 | - | μA |
| Input Voltage Range | VIN | 0 | - | VDD | V | |
| Output Voltage Range | VOUT | 0 | - | VDD-1 | V | |
| Output Current | IOUT | Continuous | - | 200 | - | mA |
| Output Impedance | ZOUT | - | 1.5 | - | Ω | |
| Power Dissipation | PD | - | - | 1000 | mW | |
| Operating Temperature Range | Toper | -40 | - | 85 | °C | |
| Storage Temperature Range | Tstg | -65 | - | 150 | °C |
Power Supply:
Input Signal:
Output Signal:
Thermal Management:
Storage and Handling:
Pin Configuration:
Testing:
Safety:
General Description
The MAX1232 microprocessor (μP) supervisory circuit provides μP housekeeping and power-supply supervision functions while consuming only 1/10th the power of the DS1232. The MAX1232 enhances circuit reliability in μP systems by monitoring the power supply, monitoring the software execution, and providing a debounced manual reset input. The MAX1232 is a plug-in upgrade of the Dallas DS1232.
Features
● Consumes 1/10th the Power of the DS1232
● Precision Voltage Monitor — Adjustable +4.5V or +4.75V
● Power-OK/Reset Pulse Width — 250ms Min
● No External Components
● Adjustable Watchdog Timer — 150ms, 600ms, or 1.2s
● Debounced Manual Reset Input for External Override
● Available in 8-Pin PDIP/SO and 16-Pin Wide SO Packages
Applications
● Computers
● Controllers
● Intelligent Instruments
● Critical μP Power Monitoring
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $1.68360 | US $1.51524 | US $1.51524 |
| ≥5: | US $1.12240 | US $1.01016 | US $5.05080 |
| ≥10: | US $1.01016 | US $0.90914 | US $9.09140 |
| ≥20: | US $0.98210 | US $0.88389 | US $17.67780 |
| ≥50: | US $0.95404 | US $0.85864 | US $42.93200 |
| ≥100: | US $0.92598 | US $0.83338 | US $83.33800 |
| ≥200: | US $0.89792 | US $0.80813 | US $161.62600 |
| ≥500: | US $0.88670 | US $0.79803 | US $399.01500 |
| ≥1000: | US $0.86986 | US $0.78287 | US $782.87000 |
Substitute (equivalent) Product
| Substitute Product | Brief Description |
|---|---|
| ADM705ARNZ | Microprocessor supervisory circuit with watchdog timer, ensuring system reliability by monitoring supply voltage. |
| DS1232 | A watchdog timer and power monitor IC for ensuring safe microprocessor operations, featuring power-fail reset. |
| TC1232EOA | Supervisory circuit combining a power-on reset generator and watchdog timer, used for microcontroller systems. |
| MCP1316T-29LE/OT | Voltage supervisor with reset timeout, monitoring supply voltage and generating reset signals for processors. |
| STM812T | Low-power microprocessor reset circuit with watchdog functionality, used in power management applications. |
| TPS3823-50DBVR | A precise supervisory circuit with power-on reset and watchdog timer, suitable for microcontroller systems. |
Product Usage
The MAX1232CPA is a microprocessor (μP) supervisory circuit used in various applications to monitor the health and operation of microprocessor-based systems. Here are some types of circuits and applications where the MAX1232CPA might be used:
Microcontroller Reset Circuits:
Embedded Systems:
Computing Systems:
Industrial Control Systems:
Networking Devices:
Consumer Electronics:
Battery-Powered Devices:
Medical Devices:
These applications utilize the key features of the MAX1232CPA such as supply voltage monitoring, reset signal generation, and watchdog functionality to maintain reliability and stability in microprocessor-based systems.
