TRANSISTOR | BJT POWER MODULE | 3-PH BRIDGE | DARLINGTON | 450V VBRCEO | 100A IC
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
Preview of the first 3 pages of the data sheet
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $61.38000 | US $57.69720 | US $57.69720 |
| ≥2: | US $61.38000 | US $57.69720 | US $115.39440 |
| ≥5: | US $57.28800 | US $53.85072 | US $269.25360 |
| ≥10: | US $57.28800 | US $53.85072 | US $538.50720 |
| ≥20: | US $57.28800 | US $53.85072 | US $1077.01440 |
| ≥30: | US $57.28800 | US $53.85072 | US $1615.52160 |
| ≥50: | US $57.28800 | US $53.85072 | US $2692.53600 |
| ≥100: | US $56.87880 | US $53.46607 | US $5346.60700 |
| ≥500: | US $56.46960 | US $53.08142 | US $26540.71000 |
Substitute (equivalent) Product
| Substitute Product | Brief Description |
|---|---|
| 6DI100M-050 | Original product: 6-pack IGBT module, 100A, 500V |
| Mitsubishi CM100DU-24F | Similar to 6DI100M-050: Dual IGBT module, 100A, 1200V |
| Fuji 7MBR100U4B120 | 7-pack IGBT module, 100A, 1200V |
| Infineon FZ1000R33HE4 | Single IGBT module, 1000A, 3300V (Higher rating substitute) |
| Toshiba MG100Q1US1 | IGBT module, 100A, 600V |
| Semikron SKM100GB12T4 | 3-phase bridge IGBT module, 100A, 1200V |
| Vishay VS-GP100TD1K30 | IGBT module, 100A, 1200V |
| IXYS MCC100-06io1B | Single-phase bridge IGBT, 100A, 600V |
Product Usage
The 6DI100M-050 is a power semiconductor module manufactured by Fuji Electric. It is an IGBT (Insulated Gate Bipolar Transistor) module, specifically designed for high-power applications. This module has a rating of 100A and 600V and contains six IGBT devices. Such modules are commonly used in various circuits and applications, including:
Inverters: Used in motor drive inverters for industrial applications, including AC motor drives, variable frequency drives (VFDs), electric vehicle (EV) traction inverters, and renewable energy inverters such as those for solar and wind power systems.
DC-DC Converters: Suitable for high-power DC-DC converter designs where efficient power conversion is necessary, often found in industrial power supplies, telecommunications, and battery charging systems.
Uninterruptible Power Supplies (UPS): Used to manage the switchover between utility power and battery power during outages, ensuring a continuous power supply for critical systems.
Welders and Plasma Cutters: Employed in industrial welding machines and plasma cutting systems that require controlled, high-power outputs.
Switch-mode Power Supplies (SMPS): Used in high-power SMPS for various industrial equipment, providing efficient power conversion and regulation.
Energy Storage Systems (ESS): Employed in ESS, particularly in conjunction with renewable energy sources, to manage power storage and delivery from battery banks.
HVAC Systems: Utilized in heating, ventilation, and air conditioning (HVAC) systems for controlling power to motors and compressors.
Induction Heating: Used in induction heating applications for industrial processes like metal hardening, melting, and soldering.
When designing circuits featuring the 6DI100M-050 module, engineers need to ensure proper thermal management, gate driver design, protection circuitry (overcurrent and overvoltage protection), and layout considerations to leverage the module's high power capacity and efficiency.
