Description
MOSFET Driver Single, Low Side, 4.5V-18V supply, 3A peak out
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
1. Description
The FAN3100TSX is a high-speed low-side Gate Driver for high-efficiency MOSFET switching. The FAN3100 2A gate driver is designed to drive an N-channel enhancement-mode MOSFET in low-side switching applications by providing high peak current pulses during the short switching intervals. The driver is available with TTL input thresholds. Internal circuitry provides an under-voltage lockout function by holding the output low until the supply voltage is within the operating range. The FAN3100 delivers fast MOSFET switching performance, which helps maximize efficiency in high-frequency power converter designs. The FAN3100 drivers trade; architecture for the final output stage. This bipolar-MOSFET combination provides high peak current during the Miller plateau stage of the MOSFET turn-on/turn-off process to minimize switching loss, while providing rail-to-rail voltage swing and reverse current capability.
2. Features
> Dual-logic inputs allow configuration as non-inverting or inverting with enable function
> Internal resistors turn driver off if no inputs
3. Product Information
Low Side | |
Peak Output Current: | 3A |
Supply Voltage Min: | 4.5V |
Supply Voltage Max: | 18V |
Driver Case Style: | SOT-23 |
No. of Pins: | 5Pins |
Input Delay: | |
Output Delay: | |
Operating Temperature Min: | -40°C |
Operating Temperature Max: | 125°C |
Packaging: | Cut Tape |
Product Range: | - |
Module Configuration: | Low Side |
Device Type: | MOSFET Driver |
MSL: | - |
Output Resistance: | 10 ohm |
Supply Voltage Range: | 4.5V to 18V |
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $1.77246 | US $1.59521 | US $1.59521 |
| ≥5: | US $1.18164 | US $1.06348 | US $5.31740 |
| ≥10: | US $1.06348 | US $0.95713 | US $9.57130 |
| ≥20: | US $1.03394 | US $0.93055 | US $18.61100 |
| ≥50: | US $1.00439 | US $0.90395 | US $45.19750 |
| ≥100: | US $0.97485 | US $0.87736 | US $87.73600 |
| ≥200: | US $0.94531 | US $0.85078 | US $170.15600 |
| ≥500: | US $0.93350 | US $0.84015 | US $420.07500 |
| ≥1000: | US $0.91577 | US $0.82419 | US $824.19000 |
Substitute (equivalent) Product
| Product Name | Description |
|---|---|
| FAN3242 | High-Speed Power MOSFET Driver, 8-Pin SOIC Package |
| FAN7382 | High-Side Power MOSFET Driver, 8-Pin PDIP Package |
| FAN7392 | Dual High-Speed Gate Driver, 8-Pin SOIC Package |
| IR2110 | High and Low Side Driver, 16-Pin DIP Package |
| TLP250 | Optically Isolated Gate Driver, 16-Pin DIP Package |
Product Usage
The FAN3100TSX is a high-speed gate driver IC designed by Fairchild Semiconductor (now part of ON Semiconductor). It is commonly used in circuits that require the efficient and rapid switching of power MOSFETs or IGBTs, particularly in applications where high-frequency operation and low propagation delay are critical. Here are some specific types of circuits where you might find the FAN3100TSX:
Power Supplies:
Motor Control:
Lighting Applications:
Renewable Energy Systems:
Industrial Automation:
Consumer Electronics:
Automotive Applications:
Medical Equipment:
The FAN3100TSX is chosen for these applications due to its high-speed performance, low propagation delay, and ability to drive high-current loads efficiently. Its features make it suitable for a wide range of high-performance power electronics circuits.
