Description
The IRS21850SPBF is a high voltage high speed power MOSFET and IGBT single High-side Gate Driver IC with propagation delay matched output channels. Proprietary HVIC and latch immune CMOS technology enables ruggedized monolithic construction. The floating logic input is compatible with standard CMOS or LSTTL output and down to 3.3V logic and can be operated up to 600V above the ground. The output driver features a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive a N-channel power MOSFET or IGBT in the high-side configuration, which operates up to 600V.
Title
IGBT/MOSFET Gate Driver, High Side, 10V-20V Supply, 4A Out, 160ns Delay, SOIC-8
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
| Parameter | Symbol | Min | Typ | Max | Unit | Conditions |
|---|---|---|---|---|---|---|
| Supply Voltage | VCC | 10 | - | 20 | V | - |
| Undervoltage Lockout (UVLO) Threshold | VUVLO | - | 10.0 | - | V | Rising |
| UVLO Hysteresis | ΔVUVLO | - | 0.8 | - | V | - |
| High-Side Driver Output Current | IHSD | - | 1.5 | - | A | - |
| Low-Side Driver Output Current | ILSD | - | 1.5 | - | A | - |
| Propagation Delay Time | td | 40 | - | 90 | ns | - |
| Pulse Width Distortion | tPWD | - | 15 | - | ns | - |
| Maximum Operating Frequency | fMAX | - | - | 500 | kHz | - |
| Maximum Junction Temperature | TJ(MAX) | - | - | 150 | °C | - |
| Storage Temperature Range | TSTG | -40 | - | 150 | °C | - |
Supply Voltage (VCC):
Undervoltage Lockout (UVLO):
Driver Output Current:
Propagation Delay Time (td):
Pulse Width Distortion (tPWD):
Maximum Operating Frequency (fMAX):
Maximum Junction Temperature (TJ(MAX)):
Storage Temperature Range (TSTG):
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $2.74000 | US $2.46600 | US $2.46600 |
| ≥5: | US $2.60300 | US $2.34270 | US $11.71350 |
| ≥10: | US $2.46600 | US $2.21940 | US $22.19400 |
| ≥20: | US $2.39750 | US $2.15775 | US $43.15500 |
| ≥50: | US $2.32900 | US $2.09610 | US $104.80500 |
| ≥100: | US $2.26050 | US $2.03445 | US $203.44500 |
| ≥200: | US $2.19200 | US $1.97280 | US $394.56000 |
| ≥500: | US $2.16460 | US $1.94814 | US $974.07000 |
| ≥1000: | US $2.12350 | US $1.91115 | US $1911.15000 |
Substitute (equivalent) Product
| Product Name | Description |
|---|---|
| IRS2184SPBF | 600V Half-Bridge Driver IC with independent high-side and low-side output channels, suitable for high-voltage, high-speed applications. |
| IR2110 | High and low side driver, designed for higher voltage and larger current applications, suitable for driving both N-channel MOSFETs and IGBTs. |
| IR2113 | 600V high-side and low-side driver with independent logic inputs, ideal for driving power MOSFETs and IGBTs. |
| IR2184 | 600V half-bridge driver with floating channel, designed for bootstrap operation and high-speed switching. |
| IRS2186 | High and low side driver IC with built-in dead-time protection and shoot-through prevention, for high-voltage applications. |
The product descriptions and links provide potential substitutes for the IRS21850SPBF electronic component.
Product Usage
The IRS21850SPBF is a high-voltage, high-speed power MOSFET and IGBT driver designed for various applications in motor control, power conversion, and other high-power electronic systems. Below are some typical circuits and applications that utilize the IRS21850SPBF:
Motor Control Circuits:
Power Inverters:
Switched-Mode Power Supplies (SMPS):
DC-DC Converters:
Industrial Drives:
Electric Vehicle (EV) Powertrains:
Renewable Energy Systems:
Given these features and applications, the IRS21850SPBF is a versatile and robust choice for a wide range of high-power, high-voltage, and high-speed electronic circuits and systems.
When designing circuits with the IRS21850SPBF, it is essential to pay attention to aspects such as power dissipation, layout considerations to minimize noise coupling, proper gate resistor selection, and ensuring the bootstrap capacitor is appropriately chosen to handle the dynamic current requirements. Proper thermal management is also crucial to ensure reliable operation under high power conditions.
